CAREDDI 1Liter Supercritical co2 extraction machine

2025-03-31
CAREDDI
SCFE-1Liter

产品详情

CAREDDI 1Liter Supercritical co2 extraction machine
萃取设备
Supercritical co2 extraction machine,Supercritical fluid extraction machine,herbal plants extraction machine,botanical oils extraction machine,essential oil extraction machine
1 Set
20 Sets/Month
T/T, L/C
40-50 days
中国,北美洲,中/南美洲,西欧,东欧,大洋洲,亚洲,中东,非洲
CAREDDI
SCFE-1Liter

产品描述

Main Technical Parameters of Supercritical Co2 extraction System 1Liter

Sn.NameSpecificationQTY
1Extraction vesselVolume: 1LDesign pressure: 50MPa Maximum work pressure: 45MPa,Design temperature: 85℃ Maximum work temperature: 80℃Material: Stainless steel 304Equipped with jacket water circling heating system, temperature adjustable.1
2Separation 1Volume: 0.5LDesign pressure: 20MPa Maximum work pressure: 18MPa,Design temperature: 85℃ Maximum work temperature: 80℃Material: Stainless steel 304Equipped with jacket water circling heating system, temperature adjustable.1
3Separation 2Volume: 0.4LDesign pressure: 20MPa Maximum work pressure: 18MPa,Design temperature: 85℃ Maximum work temperature: 80℃Material: Stainless steel 304Equipped with jacket water circling heating system, temperature adjustable.1
4cylindersMaterial: Stainless steel 304 (SS316 optional if needed)Load of extraction raw materials2
5CO2 high pressure pumpTriple plunger pump, 50L/h (frequency adjustable)To deliver CO2 into the system and increase the pressure1
6Co-solvent pump4L/h, to pump co-solvent into system1
7Water pumpsTo pump water in tank into vessel jacket and circulatedsets
8chillerChilling gaseous CO2 into liquid CO2 and cool the main pump head1
9Heat exchange systemMaterial: 304 stainless steel, design pressure 50Mpa3
10FilterMaterial: stainless steel 304 Volume: 0.5L Design pressure:20Mpa1
11mixerMaterial: stainless steel 304 Volume: 0.5L Design pressure:50Mpa1
12CO2 Storage TankMaterial: Stainless steel 304 Volume: 4L, Maximum working pressure does not exceed 16MPa1
13CO2 Cylinder rackMaterial: Stainless steel 304 , vertical or horizontal1
14Flow MeterFlow range: 0-60L/h (Display instantaneous flow)1
15Temperature control systemTemperature control range: room temperature ~ 85℃ adjustableTemperature control accuracy: ±1℃
16Safety protection systemExtraction vessel, separation vessels, CO2 high pressure pump, storage tank are equipped with safety valves to prevent system overpressure.
17Pipeline valvesHigh pressure pipelines and valves, process water valves and pipelines, check valves, back pressure valves
18Equipment bracketMaterial: Stainless steel 3041
19Data acquisition and control systemTouch screen, control extraction and separation temperatures, start and stop of CO2 high pressure pump and co-solvent pump, data storage and output.1


原理
Supercritical CO₂ extraction utilizes carbon dioxide above its critical point (31°C, 73 atm), where it exhibits both gas-like diffusivity and liquid-like density. This supercritical CO₂ acts as a solvent, penetrating materials to dissolve and extract targ
产品优势
Advantages of Our Equipment: Eco-friendly: Uses non-toxic, recyclable CO₂, leaving no solvent residues. Precision: Adjustable parameters ensure high-purity extracts with retained bioactive properties. Efficient: Low-temperature process protects h
主要特征

Careddi Technology CO., Ltd., a professional manufacturer of Supercritical Carbon Dioxide Extraction Machines located in Hai’an city, Jiangsu Province, China. Our whole plant covers an area of 30 acres and we are proud to say that we have achieved tremendous success in the Supercritical CO2 Extractor field during the past three decades.

Our machines are widely used for herb essential oils extraction and separation in pharmaceutical, food, cosmetic, and spice industries, among others. Careddi Supercritical CO2 Extraction Machines are the most advanced extraction method with a clean process, low temperature, and non-damaged ingredients inside the materials. Moreover, our machines have many advantages such as highly-integrated system with high capacity, easy installation and operation, precise pressure control, quick pressure increase, double safety protection, fast extraction speed, and 99% CO2 recovery rate.

What sets us apart from other brands is our strong technical team, which consists of more than 100 professional and skilled engineers who have been working with experts and scholars from famous universities and institutes in China for more than 35 years. We can produce a full series of Supercritical CO2 Extraction machines from lab scale for lab testing applications to large industry scale for commercial mass production applications.

At Careddi, we are dedicated to strict quality control and thoughtful customer service. We have obtained CE certificates, ISO 9001 certificate, ASME certificate, PED certificate, among others, which are useful in helping our customers establish GMP standard facilities. Our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction.

企业案例

CAREDDI has been supplying clients in over 80 countries worldwide with high reputation machines, good services, and competitive prices for various kinds of material oil extraction, especially for hemp CBD oil, hops, seabuckthorn seeds oil, frankincense oil, astaxanthin, ganoderma spore oil, agarwood oil, sandalwood oil, curcuma oil, spices oil, ginger, decaffeination, kava, nutmeg, lavender, rosemary, Rice bran oil, olive residue cake oil, tea tree seed, protein powder, and more.

We are confident in our ability to provide excellent machines and services that will meet your expectations. We look forward to the opportunity to work with you and establish a great cooperation together.
